Paulo Soares Santos

Abstract
The interrogation of optical fiber sensors (OFS) often relies on complex devices such as optical spectrum analyzers (OSAs) that are expensive with low portability and mainly suited to laboratory measurements or dedicated interrogation systems with limited spectral range. An interrogation unit was designed and fabricated using a photodetector combined with a micro-electromechanical system and a Fabry-Perot interferometer (MEMS-FPI) working as a tunable filter with a response in the range 1350-1650 nm. Deconvolution techniques were applied to mitigate the effect of the broadband response of the tunable filter on the measured signal. The performance of the unit was validated with the interrogation of long-period fiber gratings (LPFGs) as temperature, refractive index (RI), and relative humidity (RH) sensors. For the temperature, a sensitivity of 0.135 +/- 0.007 nm/degrees C was obtained, which showed a 4.9% relative error when compared to the same measurement with an OSA. For the RI, a sensitivity of 147 +/- 11 nm/RIU was obtained, which showed a relative error lower than 1% when compared to the OSA. For the humidity, sensitivities of 0.742 +/- 0.005 and 0.056 +/- 0.006 nm/%RH were obtained, with errors of 2.75% and 6.67%, respectively, when compared to a commercial dedicated interrogation system. The low relative error obtained when compared to commercial alternatives shows the potential of the system to be used in real-time applications that require portability, low cost, energy efficiency, and capacity for integration in dedicated systems.

Abstract
The increasing demand for precise chemical and biological sensing has led to the development of highly efficient plasmonic optical fiber sensors. Therefore, it is essential to optimize and match the operating wavelength region of both the optical fiber configuration and localized surface plasmon resonance of nanoparticles (NPs). This can be achieved by developing NPs that can reach resonance at near-infrared wavelengths, where refractive index sensitivity is enhanced, and silica optical fibers have lower losses. High aspect-ratio bimetallic Au@Ag nanorods and different side-polished fiber structures are tested using numerical simulations. The selected optical fiber configuration was based on a side-polished fiber with a 1 mm polished section. It is compared power losses and power at the NP interface for two configurations: a step-index single-mode fiber (SMF) with core/cladding diameters of 8.2/125 µm and a multimode graded-index fiber (GIF) with 62.5/125 µm at various polishing depths. The results showed that the best performance for both configurations was achieved at similar polishing depths, namely 59.5 and 55.2 µm for the SMF and GIF, respectively. The optical impact of retardation effects due to the proximity with the fiber structure were also observed, which caused a reduction in sensitivity from 1750 nm/RIU to 1500 nm/RIU and a red-shift of around 70 nm. © 2023 SPIE.

Abstract
Nanoparticles create localized surface plasmonic resonances (LSPR) with lower surrounding refractive index (SRI) sensitivities than their propagating SPR counterpart, originated in thin films. Historically, LSPR SRI sensitivities enhancements were achieved through spectral analysis methods that focus on unique spectral features. Herein, a study using that methodology was applied on SPR devices resulting in an increased sensitivity to SRI. It was found that by applying the inflection point method on optical fiber SPR sensors resulted in both sensitivity and resolution increments up to 44 and 35 %, respectively, in the SRI range from 1.3333 to 1.4150. Thus, successfully improving sensing capabilities of SPR based optical fiber sensors. © 2022, Universidade do Porto - Faculdade de Engenharia. All rights reserved.

Abstract
Optical fiber gratings have long shown their sensing capabilities. One of the main challenges, however, is the interrogation method applied, since typical systems tend to use broadband light sources with optical spectrum analyzers, laser scanning units or CCD (Charged Coupled Device) spectrometers. The following paper presents the development of an interrogation system, which explores the temperature response of a multimode laser diode, in order to interrogate long period fiber gratings. By performing a spectral sweep along one of its rejection bands, a discrete attenuation spectrum is created. Through a curve fitting technique, the original spectrum is restored. The built unit, while presenting a substantially reduced cost compared with typical interrogation systems, is capable of interrogating along a 10 nm window with measurement errors reaching minimum values as low as 0.4 nm, regarding the grating central wavelength, and 0.4 dB for its attenuation. Given its low cost and reduced dimensions, the developed system shows potential for slow-changing field applications.

Abstract
Surface plasmon resonance (SPR) and localized surface plasmon resonance (LSPR) are among the most common and powerful label-free refractive index-based biosensing techniques available nowadays. Focusing on LSPR sensors, their performance is highly dependent on the size, shape, and nature of the nanomaterial employed. Indeed, the tailoring of those parameters allows the development of LSPR sensors with a tunable wavelength range between the ultra-violet (UV) and near infra-red (NIR). Furthermore, dealing with LSPR along optical fiber technology, with their low attenuation coefficients at NIR, allow for the possibility to create ultra-sensitive and long-range sensing networks to be deployed in a variety of both biological and chemical sensors. This work provides a detailed review of the key science underpinning such systems as well as recent progress in the development of several LSPR-based biosensors in the NIR wavelengths, including an overview of the LSPR phenomena along recent developments in the field of nanomaterials and nanostructure development towards NIR sensing. The review ends with a consideration of key advances in terms of nanostructure characteristics for LSPR sensing and prospects for future research and advances in this field.
